Refrigerators & Freezers

Refrigerated storage cabinets for dead bodies 1, 2, 3, 4 or more

Mortuary Cabinet

Mortuary cabinets are low temperature refrigerated cabinets that are used to keep dead bodies for short or long time. These units are widely used at hospitals, railways, airports, disaster camps and army etc. These cabinets are also called by other names such as morgue freezer, deal body storage refrigerator and mortuary fridge. Usually the temperature of mortuary cabinet remains between 2°C to 5°C but in some cases freezing temperature up to 0°C, -10°C and -15°C can also be designed.

We are mortuary cabinet manufacturers in Delhi, NCR India. Our standard mortuary cabinets are available in one, two, three, four, six and eight bodies; we also made customized units for larger sizes. These cabinets or chambers are energy efficient and also provide excellent cooling performance anywhere they are used.

Mortuary cabinet temperature remains between 2°C to 5°C which is adjusted through digital PID controller; it displays both SV (set value) and PV (process value). Each chamber has trolley which is made of stainless steel and runs on rollers. Doors are solid and fixed on study SS hinges. Standard models come with external cabinets made of powder coated GI sheet but it can be made of SS 304 if needed as an option. The gap between two walls is filled with 2.5 inches PUF insulation. These cabinets require 220 volts 50Hz power supply to run.

If you want to know mortuary cabinet price, please email us your query or just make a call to us.

TECHNICAL SPECIFICATIONS

Temperature range 2°C to 8°C
Temperature controller Digital PID controller
Display of SV & PV
External cabinet Powder coated GI sheet
Inner construction Stainless steel 304
Trolley Made of stainless steel
Run on rollers fitted with ball bearings
Doors
  • Solid insulated doors
  • Fixed on SS hinges
  • Door latch
Refrigeration
  • CFC free refrigeration system
  • Hermetically sealed compressor
  • R134a or R404 refrigerants
Air circulation Axial fan
Insulation PUF
Illumination LED light
Power supply 220 Volts 50Hz
Optional
  • External cabinet made of SS 304
  • Temperature display during power failure
  • Freezing temperature 0°C, -10°C, -15°C
  • Data logger & RS232 interface
  • Temperature chart recorder
  • Temperature high / low alarm
  • Voltage stabilizer


Standard Sizes / Dimensions

Model No. of bodies
STXMRC1 1 (One) Body
STXMRC2 2 (Two) Bodies
STXMRC3 3 (Three) Bodies
STXMRC4 4 (Four) Bodies
STXMRC6 6 (Six) Bodies
STXMRC8 8 (Eight) Bodies

Mortuary Cabinet
Submit Your Request

Need Customization?
Let us design mortuary cabinet as per number of bodies
