A Kahn Shaker is a kind of reciprocating shaker used in laboratory research. It provides smooth and powerful (Horizontal) reciprocating motion for mixing, agitating and blending. Usually Kahn Shaker is made in compact design which is ideal for laboratories but we also make large units for industrial applications. It is fitted with a DC motor driven shaking mechanism and a speed regulator to control the shaking speed. There is a LED display of RPM fitted on the control panel. Housing made of powder coated mild steel with support of heavy duty metal angles. In order to hold flasks and bottles, there are steel rods with rubber sleeve. The gap between rods are adjustable.
TECHNICAL SPECIFICATIONS
| Model |
STXKHS20 |
STXKHS30 |
STXKHS36 |
| Dimensions |
20*13*4 inch |
31*17*4 inch |
36*18*4 inch |
| Shaking motion |
Horizontal Reciprocating motion |
| Motor |
Imported DC motor |
| RPM |
Up to 250 RPM |
| RPM control |
Speed regulator |
| Timer |
0-999 minutes |
| Cabinet |
Powder coated MS |
| Flask holder |
Adjustable Steel rods with rubber sleeve |
| Power supply |
220-230V/50Hz |
