We make high temperature ovens for diesel particulate filters (DPF). These DPF ovens are also known as DPF Furnace that can work on 650°C temperature easily. Their maximum temperature range of this oven is 900°C and fitted with PID temperature controller with K type thermocouple. It maintains set temperature level inside the chamber. This PID temperature controller has in-built programmable timer for profile settings; you can set desired ramp rate to heat up the chamber and hold. The heating chamber of this DPF Oven Furnace is made of ceramic blocks. Kanthal wire heaters are fitted to generate heat inside. External cabinet is made of heavy duty MS angled frame and powder coated. A vent is also provided at top of the machine for fume exhaust.
Features & Benefites
- Maximum temperature up to 800°C
- Programmable temperature controller
- Auto-shut off when cycle complete
- Over temperature protection
- Robust construction for long operation
- Can be customized according to size
Technical Specifications
| Maximum working temperature |
800°C |
| Inner chamber |
Ceramic heating blocks |
| External cabinet |
Heavy duty angled MS frame powder coated |
| Controller |
- PID temperature controller
- Display of SV & PV
|
| Temperature sensor |
K type thermocouple |
| Heating element |
Kanthal wire heating element |
| Safety feature |
- Over temperature protection
- Door safety limit switch
|
| Power supply |
440 Volts 50 Hz Three Phase |
| Optional |
- Loading trolley
- Digital timer 999 hours
- Temperature chart recorder
- PLC based HMI controller w/ data monitoring
|
STANDARD SIZES / DIMENSIONS
| Model No. |
Inner Chamber (W x H x D) |
Inner Chamber (W x H x D) |
Volume |
| STXDPF95 |
450 x 450 x 450 mm |
18 x 18 x 18 Inch |
95 Liter |
| STXDPF200 |
600 x 600 x 600 mm |
24 x 24 x 24 Inch |
216 Liters |
| STXDPF340 |
900 x 900 x 900 mm |
36 x 36 x 36 Inch |
340 Liters |
