Lyophilizer or freeze dryer with upright cooling condenser or trays

Vacuum Freeze Dryer (Lyophilizer)

A lyophilizer, also known as a freeze dryer, is a machine or device used to remove moisture or water from a substance by freeze-drying or sublimation. Freeze-drying is a process where a substance is frozen to a very low temperature and then the moisture or water is removed by sublimation, which is the direct transition of a substance from solid to gas without going through the liquid state.

Lyophilizers are commonly used in various fields, including pharmaceuticals, biotechnology, food preservation, and research laboratories. They are used to preserve perishable materials, such as drugs, vaccines, biological samples, and food items, by removing moisture without damaging the structure or properties of the material. Lyophilization is considered a gentle and effective method of drying, as it preserves the integrity of the material and can result in a longer shelf life compared to other drying methods.

Freeze Dryer is a vacuum drying equipment fitted with a cryogenic system is used to remove moisture from sensitive products and make them dry without any damage. These freeze dried products can be rehydrated later on. This equipment is also called lyophilizer and widely used in food and pharmaceutical industries.

We manufacture lyophilizers or freeze dryers for food and pharmaceutical research and development applications. We supply wide range of freeze dryers that are available in benchtop model, floor standing model and pilot industrial scale. Standard models come with cold trap (ice condenser) temperature -55°C but we can also make -80°C if required. Each vacuum freezer dryer or lyophilizer comes with color touch screen control panel with intuitive menu; which helps user to operate the machine without any training. The standard models come in 3 liters, 5 liters and up to 25 liters. These lyophilizers deliver rapid and safe freeze drying of your high quality products and known for advanced refrigeration and vacuum technology. Each machine is capable of removing water as well as organic solvents such as acetone, acetonitrile, methanol, ethanol etc. Please email us your query for price list, quotation and customized requirements.

TECHNICAL SPECIFICATIONS

Model STXFD-10-R STXFD-10-MR STXFD-18-R STXFD-18-MR STXFD-18-MTP-80
Total Shelf Area 0.12m2 0.12m2 0.18m2 0.18m2 0.09 m2
Shelf size ø200 mm*4 Nos. ø200 mm*3 Nos.
Vials load Ø12mm*920pcs
Ø16mm*480pcs
Ø22mm*260pcs
Ø12mm*920pcs
Ø16mm*480pcs
Ø22mm*260pcs
Ø12mm*1320pcs
Ø16mm*740pcs
Ø22mm*360pcs
Ø12mm*1320pcs
Ø16mm*740pcs
Ø22mm*360pcs
Ø12mm*990pcs
Ø16mm*555pcs
Ø22mm*270pcs
Sample load capacity 1.2L 1.2L 1.2L ~ 2.7L 1.2L ~ 2.7L 0.9 L
Stopper / / / / yes
Flask / Manifolds / 8 Nos. / 8 Nos.
Condenser Temperature <-55°C (-80°C optional) -80°C
Cold trap size 215*140 mm (Dia.*Height) 270*400 mm (Dia.*Height)
Defrost type Natural
Vacuum level <5Pa
Vacuum Pump 2L/S oil filled vacuum pump 4L/S oil filled vacuum pump
Condenser Capacity 3-4kg/24h 3-4kg/24h 6kg/24h

6kg/24h

Power 750W 750W 1400W

1400W

Power supply

220V/50Hz

Optional

-80°C condenser
Electric defrost function
Oil mist filter
Shelves heating & program segment control (16 programs can be stored)
Extra shelves
Flask of 100ml, 250 ml and 500 ml
