Detailed Description
- Construction: Our plant growth chambers are ruggedly designed with thick gauge of stainless steel 304 chamber and exterior is made of powder coated GI sheet for corrosion resistance surface. High density PUF insulation of 70mm is filled between inner and external walls. Main chamber is nicely fabricated with arc welding. These growth chambers are made in 150 liters to 1000 liters or more like walkin chambers. Caster wheels with brake are fitted for easy mobility of chambers.
- Doors: Each plant growth chamber has two doors; one for observation and fitted directly at the inner chamber allows you view plants inside without deforming inner conditions. The exterior door is solid and PUF insulated and fitted with easy to use latch handle.
- Temperature & Humidity: The temperature range is 5°C to 60°C and humidity range is 50% to 90%. These parameters are controlled through imported PID controller which features excellent accuracy and uniformity with PT100 temperature and capacitive humidity sensors. Tubular air heaters are used for temperature and for humidity, stainless steel tank with immersion heater is used with automatic water filling facility.
- Illumination: Illumination plays important role in effective plant growth condition; therefore, we use high quality growth lights at three sides of the chamber. These lights are controlled through cyclic timer for 24X7 a week. These lights can be easily changed or replaced at user level.
- Optional: We also equip our plant growth chambers with some advance features such as PLC based HMI controller. It features color touch screen having display and control of temperature and humidity with data monitoring and storage and also facility USB interface to transfer data into pen drive. We also make 30mm port hole for external wires and validation.
FEATURES & ADVANTAGES
- Accuracy of temperature, humidity & light
- Made according to plant height
- Digital control panel
- Digital light timer
- Height adjustable shelves
- Durable construction
TECHNICAL SPECIFICATIONS
| Temperature range | Lights Off: 5°C to 60°C Light ON: 10°C to 60°C |
| Temperature controller | Digital PID controller with SV & PV values |
| Temperature accuracy | ±1% |
| Humidity range | 50% to 90% |
| Humidity controller | Digital PID controller with SV & PV values |
| Humidity accuracy | ±3% |
| Illumination | 3 sides illumination with detachable LED lights (10000 LUX or 23000 LUX) |
| Light timer | 24x7 weekly digital timer |
| Air circulation | Forced air circulation through axial fans |
| Construction | Double walled |
| Exterior | Powder coated steel |
| Interior | Made of Stainless steel 304 with silicon gasket |
| Outer door | Insulated solid door with lock & key and magnetic gasket |
| Inner door | Toughened Glass door to view samples |
| Insulation | 3 inch thick PUF insulation |
| Shelves | Stainless steel or chrome plated (Height adjustable) |
| Heating | Tubular air heaters |
| Compressor | EMERSON Copeland brand compressor CFC free |
| Humidity system | SS boiler tank with immersion heater and automatic water replenishment by external tank |
| Safety | Audio / visual alarm for temperature deviation |
| Optional |
|
| Power supply | 220 Volts / 50 Hz |
TECHNICAL SPECIFICATIONS
| Model | Dimension (mm) | Volume (Liter) |
|---|---|---|
| STXPGC150 | 800 x 500 x 380 | 150 L |
| STXPGC250 | 550 x 450 x 1000 | 250 L |
| STXPGC350 | 550 x 550 x 1200 | 350 L |
| STXPGC600 | 800 x 600 x 1250 | 600 L |
| STXPGC800 | 1120 x 600 x 1200 | 800 L |
| STXPGC1000 | 1150 x 670 x 1300 | 1000 L |
